Remix DOCX editor example

Run the example

From the repository root, build the workspace packages before you start Remix:

bun install
bun run build:packages
bun run dev:remix

Open http://localhost:3001.

Set the client boundary

app/routes/_index.tsx uses a mount check and a lazy import. This is the shape of it, with the placeholder markup shortened:

import { lazy, Suspense, useEffect, useState } from 'react';

const Editor = lazy(() => import('../components/Editor').then((m) => ({ default: m.Editor })));

export default function Index() {
  const [mounted, setMounted] = useState(false);
  useEffect(() => setMounted(true), []);

  if (!mounted) return <div>Loading editor...</div>;
  return (
    <Suspense fallback={<div>Loading editor...</div>}>
      <Editor />
    </Suspense>
  );
}

Use both the mount check and the lazy import.

The mount check is about hydration. Remix renders the route on the server, and React compares that markup with the first client render. The editor produces different markup in the browser because it measures layout, so rendering it on both sides gives a hydration mismatch. Returning the same placeholder until mounted is true keeps the two renders identical.

The lazy import is about the server bundle. A static import pulls the editor into the server build, where its browser-only dependencies fail at module load, before any component renders. lazy() defers the import to the browser.

Remove the mount check and you get a hydration warning. Remove the lazy import and the server build fails to start.

Match the fallback to the editor

React swaps the fallback for the editor in one frame. Give the fallback the height the editor will occupy, or the page moves when it mounts. Both placeholders in _index.tsx fill the viewport height for that reason.

What the route renders

app/components/Editor.tsx renders <DocxEditor>, which supplies the title bar, menu, toolbar, and navigation pane. The modules prop registers comments, tracked changes, and suggesting mode, and <DocxEditorReview /> mounts the review pane inside the editor.

Add the editor to Remix

Install the adapter and its required engine peer:

npm install @docx-editor.dev/react @docx-editor.dev/core

Import @docx-editor.dev/core/styles/editor.css once. Render the editor only after the component mounts.

For more information, see the Remix integration guide.
